After the setting of the associated acknowledgment bit, the remaining time is set to the interval
time and the number of output warnings is zero - assuming the associated acknowledgment
blocking bit is not set.
DB1800: Alarms
DB1800 Warnings/Alarms [r]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBB3000 Alarm 8 Alarm 7 Alarm 6 Alarm 5 Alarm 4 Alarm 3 Alarm 2 Alarm 1
DBB3001 Alarm 16 Alarm 15 Alarm 14 Alarm 13 Alarm 12 Alarm 11 Alarm 10 Alarm 9
DBB3002 Alarm 24 Alarm 23 Alarm 22 Alarm 21 Alarm 20 Alarm 19 Alarm 18 Alarm 17
DBB3003 Alarm 32 Alarm 31 Alarm 30 Alarm 29 Alarm 28 Alarm 27 Alarm 26 Alarm 25
Alarm n: The alarm bit assigned to task n.
The bit is set for one PLC cycle each as warning (remaining time ≠ 0) and as alarm (remaining time = 0).
DB1800: Deactivate tasks
DB1800 Task deactivation [r/w]
Byte Bit 7
Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBB2000 Deactiva‐
tion 8
Deactiva‐
tion 7
Deactiva‐
tion 6
Deactiva‐
tion 5
Deactiva‐
tion 4
Deactiva‐
tion 3
Deactiva‐
tion 2
Deactiva‐
tion 1
DBB2001 Deactiva‐
tion 16
Deactiva‐
tion 15
Deactiva‐
tion 14
Deactiva‐
tion 13
Deactiva‐
tion 12
Deactiva‐
tion 11
Deactiva‐
tion 10
Deactiva‐
tion 9
DBB2002 Deactiva‐
tion 24
Deactiva‐
tion 23
Deactiva‐
tion 22
Deactiva‐
tion 21
Deactiva‐
tion 20
Deactiva‐
tion 19
Deactiva‐
tion 18
Deactiva‐
tion 17
DBB2003 Deactiva‐
tion 32
Deactiva‐
tion 31
Deactiva‐
tion 30
Deactiva‐
tion 29
Deactiva‐
tion 28
Deactiva‐
tion 27
Deactiva‐
tion 26
Deactiva‐
tion 25
Deactivation n: The deactivation bit assigned to task n.
If the bit is set via SINUMERIK Operate or from the PLC user program, the current state of task n is frozen and no longer
processed.
TRUE: Task deactivated
FALSE: Task active
This means it is possible, for example, to adapt the maintenance interval according to the actual runtime of the modules.
DB1800: Acknowledgment block
DB1800 Acknowledgment block [r/w]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBB5000 Acknowl‐
edgment
block 8
Acknowl‐
edgment
block 7
Acknowl‐
edgment
block 6
Acknowl‐
edgment
block 5
Acknowl‐
edgment
block 4
Acknowl‐
edgment
block 3
Acknowl‐
edgment
block 2
Acknowl‐
edgment
block 1
DBB5001 Acknowl‐
edgment
block 16
Acknowl‐
edgment
block 15
Acknowl‐
edgment
block 14
Acknowl‐
edgment
block 13
Acknowl‐
edgment
block 12
Acknowl‐
edgment
block 11
Acknowl‐
edgment
block 10
Acknowl‐
edgment
block 9
Service Planner
7.1 Interfaces in the PLC user program
CNC commissioning
228 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
