Interface signal Meaning
DB43xx.DBWy006 – DBWy034 Job description
DB43xx.DBXy100.0
DB43xx.DBXy100.1
Positive feedback: Acknowledgment status, acknowledgment OK,
one PLC cycle pending
Negative feedback: Acknowledgment status, acknowledgment er‐
ror, static pending
DB43xx.DBXy100.0
DB43xx.DBXy100.1
Positive feedback: Acknowledgment status, one PLC cycle pending
Negative feedback: Acknowledgment status, static pending
DB43xx.DBXy100.0 Tool management feedback: Acknowledgment status
DB43xx.DBBy104 Tool management feedback: Error status
DB43xx.DBXy108.0 -
DB43xx.DBXy111.6
Map of acknowledgments for tool change: This map belongs to the
positive or negative feedback and remains valid for the same time
DB43xx.DBWy124 – DBWy138 Job status
y [= 0 or 1]: TO unit 1 or TO unit 2
xx: Spindle index / tool holder
Jobs: Interface description
DB4300...43xx Signals from tool management [r]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBBy000 Multitool:
Data in
the multi‐
tool area
-- -- -- -- -- -- Job is still
active.
DBBy001 Tool re‐
mains in
the spin‐
dle
Unload
manual
tool
Load man‐
ual tool
No old tool T0 Prepare
change
Change
tool (initi‐
ated by:
M06)
Fixed-lo‐
cation co‐
ded
DBBy002 Reserved
DBBy003 Reserved
DBBy004 Reserved
DBBy005 Reserved
DBWy006 Source magazine number for new tool (INT)
DBWy008 Source location number for new tool (INT)
DBWy010 Reserved
DBWy012 Reserved
DBWy014 Reserved
DBWy016 Reserved
DBWy018 Target magazine number for old tool (INT)
DBWy020 Target location number for old tool (INT)
DBWy022 Location type (INT)
DBWy024 Size left (INT)
DBWy026 Size right (INT)
DBWy028 Reserved
DBWy030 Reserved
Tool management
9.3 NC ↔ PLC user interface
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 273
