Siemens SINUMERIK 828D

DB4300...43xx Signals from tool management [r]
DBBy032 Tool status for a new tool:
Tool has
been in
use
Tool fixed-
location
coded
Tool be‐
ing
changed
Prewarn‐
ing limit
reached
Measur‐
ing tools
Tool disa‐
bled
Tool ena‐
bled
Active tool
DBBy033 Tool status for a new tool:
Manual
tool
1:1
Change
-- Master
tool
To be loa‐
ded
To be un‐
loaded
Blocked Identifica‐
tion for
tools in
the buffer
DBWy034 New tool: Internal T number of the NC (INT)
DBWy036 Reserved
DBWy038 Reserved
DBWy040 Reserved
DBWy042 Reserved
DBWy044
Free parameter 1 (DWORD)
DBWy046
DBWy048
Free parameter 2 (DWORD)
DBWy050
DBWy052
Free parameter 3 (DWORD)
DBWy054
DBWy056 Multitool: Type (INT)
DBWy058 Multitool: Number of locations (INT)
DBWy060
Multitool: Tool distance (FLOAT)
DBWy062
DBWy064 Multitool: Number (source) of the new tool (INT)
DBWy066 Multitool: Location number (source) of the new tool (INT)
DBWy068 Multitool: Number (target) of the old tool (INT)
DBWy070 Multitool: Location number (target) of the old tool (INT)
DBWy072 Location type (INT)
DBWy074 Size left (INT)
DBWy076 Size right (INT)
DBWy078 Size top (INT)
DBWy080 Size bottom (INT)
DBWy082 Tool status for new tool (INT)
DBWy084 T number of the tool (INT)
DBWy086 Spindle number / tool holder number (INT)
DBWy088 Multitool: Original magazine number (INT)
DBWy090 Multitool: Original location number (INT)
y [= 0 or 1]: TO unit 1 or TO unit 2
xx: Tool holder
Tool management
9.3 NC ↔ PLC user interface
CNC commissioning
274 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
