Synchronous acknowledgment
The tool is no longer in the spindle.
Transfer step From To Comment
Magazine Loca‐
tion
Magazine Location
6
DB9900.DBW40
9998 1 9999 1 Tool removed from the
spindle
Acknowledg‐
ment step
Acknowledgment bit Transfer step for
the new tool
Transfer step for
the old tool
Status
xxx DB4200.DBXx.x 0 6 105
After intermediate acknowledgment of the empty spindle and insertion of the new tool in the
spindle, the tool change is terminated with a total acknowledgment:
Acknowledg‐
ment step
Acknowledgment bit Transfer step for
the new tool
Transfer step for
the old tool
Status
DB4200.DBX0.0 (99)
Starting position 2
A manual tool is in the spindle and is to be replaced by a tool from the magazine.
Job from tool management to the PLC user program (tool change):
DB4300.DBX0.0, DBX1.2 and DBX1.6 ("Prepare tool change")
DB43xx.DBW6 Source magazine number 1
DB43xx.DBW8 Source location number 6
DB43xx.DBW10 Target magazine number 9999
DB43xx.DBW12 Target location number 1
Acknowledgment "Prepare tool change":
Acknowledg‐
ment step
Acknowledgment bit Transfer step for the
new tool
Transfer step for the
old tool
Status
xxx DB4200.DBXx.x 0 0 1
Displayed on the interface: DB4300.DBX0.0 /1.1 and 1.6 ("Execute tool change")
The job remains otherwise unchanged, the tools are still at the starting positions.
Tool management
9.6 Example: Change manual tools
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 301
