Note
Generally only one connection is permitted, i.e. several simultaneous connections to different
controls are not supported: Data exchange between two controls by means of "Access
MyMachine" is therefore not possible.
Direct connection
To create a direct connection:
1. The login data is entered in the dialog "Settings" → "Connection" → "Direct connection":
Figure 1-6 Dialog: Login data for direct connection
2. In the menu, select
"Connection" → "Connect" → "Direct connection" or click the "Connect"
button.
The following dialog box is displayed:
Figure 1-7 Dialog: Direct connection
3. The last selected direct
connection is highlighted. Using the "Connect" button, a connection
to the IP address196.168.215.1 is created.
This dialog does not appear when the direct connection is selected using the menu.
Scope of delivery and requirements
1.6 Communication with the control
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 27
