File
The settings for this are specified in the "slmahdconfig.ini" file.
Configuring the channel operational message
Section Meaning
CondStopIcons Specification of an icon that is to be displayed with a certain channel operational
message.
If no icon is specified for a certain channel operational message, then the icon
specified for "DefaultIcon" is displayed.
CondDelayTime Specification of how long (in milliseconds) a certain message must be present
before it is displayed.
● If
no time is
specified for a certain channel operational message, then the time
specified at "CondDelayTime" is used.
● If the channel operational message is to be displayed immediately, "0" must
be specified as time.
Procedure
1. Copy the "slmahdconfig.ini" file from the /siemens/sinumerik/hmi/template/cfg directory.
2. Place the file in the following directory: /oem/sinumerik/hmi/cfg or /user
/sinumerik/hmi/cfg.
3. Open the file and make the required settings.
"slmahdconfig.ini" file
Standard configuration
[CondStopIcons]
Default icon = condwait.png
1 = condstop.png ; No NC ready
2 = condstop.png ; No mode group ready
3 = condstop.png ; EMERGENCY STOP active
4 = condstop.png ; Alarm with stop active
5 = condstop.png ; M0/M1 active
6 = condstop.png ; Block in SBL mode terminated
7 = condstop.png ; NC stop active
8 = condstop.png ; Read-in enable missing
9 = condstop.png ; Feed enable missing
10 = condwait.png ; Dwell time active
11 = condwait.png ; Aux. function acknowledgment missing
12 = condstop.png ; Axis enable missing
13 = condwait.png ; Exact stop not reached
Customizing the "Machine" operating area
5.4 Configuring the channel operational message
SINUMERIK Operate
52 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
