Siemens SINUMERIK 828D Commissioning Manual

Function options
In the program header, a blank can be optionally set to A, B, C and table clamping:
Clamping View Machine data
A axis MD52207 $MCS_USAGE_ATTRIB bit 0 and bit 8 = 1
B axis MD52207 $MCS_USAGE_ATTRIB bit 1 and bit 8 = 1
C axis MD52207 $MCS_USAGE_ATTRIB bit 2 and bit 8 = 1
Table MD52214 $MCS_FUNCTION_MASK_MILL bit 1 = 1
Note
To obtain the selection
option in the program header, two rotary axes must be defined for the
raw part clamping.
Simulation and simultaneous recording
6.4 Clamping a blank
SINUMERIK Operate
72 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
