MD52230 $MCS_M_CODE_ALL_COOLANTS_OFF M code for all coolants Off
= 9 You define the M function to switch off the coolant that is output when the tool is changed.
MD52231 $MCS_M_CODE_COOLANT_1_ON M code for coolant 1 On
= 8 You define the M function for coolant 1 that is output when the tool is changed.
MD52232 $MCS_M_CODE_COOLANT_2_ON M code for coolant 2 On
= 7 You define the M function for coolant 2 that is output when the tool is changed.
MD52233 $MCS_M_CODE_COOLANT_1_AND_2_ON M code for both coolants On
= -1 You define the M function for coolant 1 and 2 that is output when the tool is changed.
MD52281 $MCS_TOOL_MCODE_FUNC_ON[ ] M code for tool-specific function ON
= -1 M function is not output.
If both M commands of a function "= -1", the corresponding field is not displayed on the
interface.
[0] M code for tool-specific function 1 ON
[1] M code for tool-specific function 2 ON
[2] M code for tool-specific function 3 ON
[3] M code for tool-specific function 4 ON
MD52282 $MCS_TOOL_MCODE_FUNC_OFF[ ] M code for tool-specific function OFF
= -1 M function is output.
If both M commands
of a function "= -1", the corresponding field is displayed on the interface.
[0] M code for tool-specific function 1 OFF
[1] M code for tool-specific function 2 OFF
[2] M code for tool-specific function 3 OFF
[3] M code for tool-specific function 4 OFF
Channel-specific cycle setting data
SD55212 $SCS_FUNCTION_MASK_TECH_SET Cross-technology function screen
= 6
Bit 0 Tool preselection active.
The next tool is prepared directly after a tool change.
Notice: For a revolver, the setting data must be set to "0".
Bit 1 Automatic calculation of the thread depth for metric threads.
Bit 2 Take the thread diameter and thread depth from the table.
Configuring cycles
7.4 Milling
SINUMERIK Operate
98 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
