Page #469 background imageLoading...
Page #469 background image
MD20050 $MC_AXCONF_GEOAX_ASSIGN_TAB[ ] Assignment of geometry axis to chan‐
nel axis
[0] = 1 X is channel axis 1 if TRACYL is not active
[1] = 2 Y is channel axis 2 if TRACYL is not active
[2] = 3 Z is channel axis 3 if TRACYL is not active
MD20060 $MC_AXCONF_GEOAX_NAME_TAB[ ] Geometry axis name in the channel
[0] = X Geometry axis 1
[1] = Y Geometry axis 2
[2] = Z Geometry axis 3
MD20070 $MC_AXCONF_MACHAX_USED[ ] Machine axis number valid in channel
[0] = 1 X as machine axis 1
[1] = 2 Y as machine axis 2
[2] = 3 Z as machine axis 3
[3] = 4 SP1 as machine axis 4
[4] = 5 A as machine axis 5
[5] = 6 C as machine axis 6
MD20080 $MC_AXCONF_CHANAX_NAME_TAB[ ] Name of channel axis in the channel
[0] = X1 Channel axis name
[1] = Y1 Channel axis name
[2] = Z1 Channel axis name
[3] = SP Channel axis name
[4] = A Channel axis name
[5] = C Channel axis name
Preparation for TRACYL
MD24200 $MC_TRAFO_TYPE_2[ ] Definition of 2nd transformation in channel
= 513 Transformation TRACYL with groove wall offset
MD24210 $MC_TRAFO_AXES_IN_2[ ] Axis assignment for transformation 2
[0] = 3 Channel axis radial to rotary axis
[1] = 6 Channel axis in cylinder surface (rotary axis)
[2] = 2 Channel axis parallel to rotary axis
[3] = 1 Channel axis special axis to index [0]
Configuring cycles
7.4 Milling
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 101
