MD24432 $MC_TRAFO_AXES_IN_5[ ] Axis assignment for transformation 5.
[0] = 5 1st transformer axis = channel axis, Y1
[1] = 1 2nd transformer axis = channel axis, X1
[2] = 2 3rd transformer axis = channel axis, Z1
MD24434 $MC_TRAFO_GEOAX_ASSIGN_TAB_5[ ] Assignment of geometry axes to channel
axes for transformation 5.
[0] = 1 1st axis = channel axis X1
[1] = 5 2nd axis = channel axis Y1
[2] = 2 3rd axis = channel axis Z1
MD24436 $MC_TRAFO_INCLUDES_TOOL_5
= 0 Tool handling with active transformation 5.
MD24700 $MC_TRAANG_ANGLE_1
= 55 Angle between 1st and 2nd transformation axis. Data set for linking (TRACON) of end
face machining on main spindle (TRANSMIT) and inclined axis (TRAANG).
Data record for linking (TRACON) of end face machining on main spindle (TRANSMIT) and
inclined axis (TRAANG):
MD24440 $MC_TRAFO_TYPE_6
= 8192 Type of transformation that is available as sixth in the channel.
MD24444 $MC_TRAFO_GEOAX_ASSIGN_TAB_6[ ] Assignment of geometry axes to channel
axes for transformation 6.
[0] = 1 1st axis = channel axis X1
[1] = 3 2nd axis = channel axis Y1
[2] = 2 3rd axis = channel axis Z1
MD24995 $MC_TRACON_CHAIN_1[ ] Transformation linking
[0] = 1 Number of the TRANSMIT transformation (main spindle) for linking.
[1] = 5 Number of the TRAANG transformation for linking. Data set for linking (TRACON) of
cylinder surface transformation on main spindle (TRACYL) and inclined axis (TRAANG).
Data record for linking (TRACON) of cylinder surface transformation on main spindle
(TRACYL) and inclined axis (TRAANG):
MD24450 $MC_TRAFO_TYPE_7
= 8192 Type of transformation 7 in the TRACON channel.
Configuring cycles
7.5 Turning
SINUMERIK Operate
130 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
