Siemens SINUMERIK 828D Commissioning Manual

NOTICE
Collision avoidance
Make sure that the
tool and the workpiece cannot collide during swivelling when moving the
tool axes.
Retracting axis Z or retracting axes Z, XY is realized as an absolute machine position at the
values of parameters $TC_CARR38[n] to $TC_CARR40[n].
$TC_CARR38[n] Retraction position X
$TC_CARR39[n] Retraction position Y
$TC_CARR40[n] Retraction position Z
The type of retraction is modified in the Manufacturer cycle CUST_800.SPF (Page 159).
Configuring cycles
7.7 Swiveling
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 149

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
