Requirement
You have already made the settings from the following section:
See also: Measuring cycles and measurement functions, general (Page 170)
Settings
General cycle setting data
SD54760 $SNS_MEA_FUNCTION_MASK_PIECE Settings for the input screen, measuring
cycles in AUTOMATIC, workpiece meas‐
urement.
Bit 1 Display select softkey 3D measurement
Bit 3
Enable probe calibration field to be selected
Bit 4 Select calibration input measuring feed
1)
Bit 6 Enable ZO to be selected in the basis reference (SETFRAME)
Bit 7 Enable ZO to be selected in the channel-specific basis frame
Bit 8 Enable ZO to be selected in the basis frame
Bit 9 Enable ZO to be selected in the adjustable frame
Bit 10 Enable ZO, coarse and fine, to be selected
Bit 11 Select tool offset, geometry and wear
Bit 12 Select tool offset, not inverted and inverted
Bit 13 Select tool offset L1, R or L1, L2, L3 R
Bit 14 Select tool offset, zero offset (_TZL)
Bit 15 Select tool offset, dimensional difference monitoring (_TDIF)
Bit 16 Select workpiece measurement with spindle reversal
Bit 17 Selects align workpiece probe in the switching direction
Bit 18 Select number of measurements (_NMSP)
Bit 19 Select offset with mean value generation (_TMV)
1)
Bit 20 Select experience values (_EVNUM)
Bit 21 Select total setting-up offset
Bit 22 Select calibration to unknown or to known center point
Bit 24 Select calibration with/without position deviation
Bit 25 Select zero offset when measuring the angulation of the spindle
Channel-specific cycle setting data
SD55630 $SCS_MEA_FEED_MEASURE Measuring feedrate [mm/rev]
= 300 Measuring feedrate when calibrating the workpiece probe
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 189
