Note
Measuring feedrate for workpiece measuring
All measuring cycles use the value saved in SD54611 $SNS_MEA_WP_FEED[n] as measuring
feedrate after the tool probe has been calibrated.
A different measuring feedrate can be assigned for each calibration field [n].
When calibrating the probe, either the measuring feedrate from SD55630
$SCS_MEA_FEED__MEASURE is used, or the measuring feedrate can be overwritten in the
input screen when calibrating. To do this, SD54760 MEA_FUNCTION_MASK_PIECE bit 4
must be set to 1.
SD55632 $SCS_MEA_FEED_RAPID_IN_PERCENT Percentage reduction
= 50 Default value of the percentage reduction of the rapid traverse velocity for internal cycle
intermediate positioning without collision monitoring.
The setting of the channel-specific cycle setting data SD55600 SCS_MEA_COLLI‐
SION_MONITORING must be = 0.
SD55634 $SCS_MEA_FEED_PLANE_VALUE Feedrate of the intermediate positioning
in the working plane with active collision
monitoring.
= 1000 Default value
SD55636 $SCS_MEA_FEED_FEEDAX_VALUE Feedrate of the intermediate positioning
in the infeed axis
with active collision mon‐
itoring.
= 1000 Default value
SD55638 $SCS_MEA_FEED_FAST_MEASURE Fast measuring feedrate
= 900 Default value
SD55640 $SCS_MEA_FEED_CIRCLE Feedrate with circle programming
= 1000 Default value
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
190 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
