SD54644 $SNS_MEA_TPW_TRIG_MINUS_DIR_AX3[k] Trigger point of the 3rd measuring axis
in the negative direction.
SD54645 $SNS_MEA_TPW_TRIG_PLUS_DIR_AX3[k] Trigger point of the 3rd measuring axis
in the positive direction.
SD54646 $SNS_MEA_TPW_EDGE_DISK_SIZE[k] Tool probe, edge length / disk diameter.
SD54647 $SNS_MEA_TPW_AX_DIR_AUTO_CAL[k] Automatic calibration of tool probe, en‐
able axes/directions
SD54648 $SNS_MEA_TPW_TYPE[k] Probe version
= 0 Cube (default value)
= 101 Disk in XY, working plane G17.
= 201 Disk in ZX, working plane G18.
= 301 Disk in YZ, working plane G19.
SD54649 $SNS_MEA_TPW_CAL_MEASURE_DEPTH[k] Distance between the upper edge of
the tool probe and lower edge of the
tool (calibration depth, measuring
depth for milling radius).
SD54650 $SNS_MEA_TPW_STATUS_GEN[k] Calibration status
SD54651 $SNS_MEA_TPW_FEED[k] Measuring feedrate when calibrating
The following general cycle setting data SD54647 $SNS_MEA_TPW_AX_DIR_AUTO_CAL is
used to define in which axes and directions it is possible to calibrate a tool probe.
Decimal place
ONES 1. Axis
= 0 axis not possible
= 1 only minus direction
= 2 only plus direction
= 3 both directions
TENS 2. Axis
= 0 axis not possible
= 1 only minus direction
= 2 only plus direction
= 3 both directions
HUNDREDS 3. Axis
= 0 axis not possible
= 1 only minus direction
= 2 only plus direction
= 3 both directions
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 195
