Page #565 background image
= 0 Only single probing with the feedrate calculated by the cycle. However, as a minimum, the
value from SD54673[0] $SNS_MEA_CM_MIN_FEEDRATE.
= ≥ 1 First probing with feedrate. However, as a minimum with the value from
SD54673[0] $SNS_MEA_CM_MIN_FEEDRATE)
SD54675[0] $SNS_MEA_CM_FEEDFACTOR_1
SD54676 $SNS_MEA_CM_FEEDFACTOR_2[0] Feedrate factor 2
= 0 Second probing with the feedrate calculated by the cycle. This is only effective for
SD54673 $SNS_MEA_CM_FEEDFACTOR_1[0] > 0, default value.
= ≥ 1 Second probing with the calculated feedrate from SD54673 $SNS_MEA_CM_MIN_FEE‐
DRATE[0] feedrate factor 2.
Third probing with the calculated feedrate.
Note
Feedrate factor 2 should be less than feedrate factor 1.
SD54677 $SNS_MEA_CM_MEASURING_ACCURACY[0] Specified measuring accuracy.
The value of this parameter always
refers to the last probing of the tool
at the probe.
= 0.005 Default value
Measurement with rotating spindle: Measured value correction using correction tables
SD54691 $SNS_MEA_T_PROBE_OFFSET Activates the measuring result cor‐
rection
= 0 No data, default value
= 1 Correction in the cycle. This is only effective if SD54690 $SNS_MEA_T_PROBE_MANUFAC‐
TURER>0.
= 2 Correction using user-defined correction table
SD54689 $SNS_MEA_T_PROBE_MANUFACTURER Activate pre-configured compensation
tables for several tool probe models
(customer-specific).
= 0 No data, default value
= 1 TT130 (Heidenhain)
= 2 TS27R (Renishaw)
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 197
