Bit 11 Reactivate tool in all monitoring types.
Bit 12 Hide reactivating tool.
SD54215 $SNS_TM_FUNCTION_MASK_SET
Bit 0 Diameter display for rotating tools.
Cutting edge parameters 6 (tool nose radius) and 15 (wear radius) are not displayed as a
radius value, but as a diameter value for the following tool types: Types 100 to 299, 580,
710, 711, 712, 713, 714 and 725.
Cutting edge parameter 7
(outside radius) is not displayed as a radius value, but as a diam‐
eter value for the following tool types: Types 140 and 714.
Bit 1 M4 is the standard direction of rotation for all turning tools. When creating turning tools, the
direction of rotation is pre-assigned with M4.
Bit 2 A name is not suggested when creating a tool.
Bit 3 Input lock, tool name and tool type for loaded tools. For loaded tools, the tool name and the
tool type can no longer be changed.
Bit 4 Input lock for loaded tools if the channel is not in the reset state.
Bit 5 Tool wear entries are added: Wear data is entered in addition to the already existing wear
value.
Bit 6 Only numerical entries are permitted in the "Tool identifier".
Bit 7 Hide tool monitoring parameters. The tool monitoring parameters are hidden in the user
interface.
Bit 8 Diameter display for face axis - geometry. The geometry value of the transverse axis is
displayed as a diameter value, if a transverse axis is defined in MD20100 $DIAME‐
TER_AX_DEF and SD42940 $TOOL_LENGTH_CONST is set to 18 and SD42950
$TOOL_LENGTH_TYPE is set to 2.
Bit 9 Diameter display for face axis - wear. The wear value of the transverse axis is displayed as
a diameter value, if a transverse axis is defined in MD20100 $DIAMETER_AX_DEF and
SD42940
$TOOL_LENGTH_CONST is set
to 18 and SD42950 $TOOL_LENGTH_TYPE is
set to 2.
Bit 10 Enable tool load/relocate to buffer storage locations. The magazine number can be entered
into the load dialog box. It is therefore possible to access the buffer storage via magazine
number 9998.
Bit 11 Creating new tools at gripper locations is blocked.
Bit 12 Measuring tools are not unloaded with the "Unload all" function.
Bit 13 The wear value is not deleted when a tool geometry value is entered.
Bit 14 Load or relocate tool. Empty location search performed without default value with the tool
magazine last used.
= 0 Empty location always starts with the tool magazine last used.
= 1: Empty location search follows the set search strategy.
Tool management
9.1 Machine data for tool management
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 225
