Entries Meaning
Width Column width in pixels in relation to a 640 x 480 resolution.
See example below: The default column width is changed to 53 pixels.
DisplayMode Values that the parameter is displayed with.
See example below: The default setting is changed to "DoubleMode".
The following values can also be accepted:
AnyMode All characters
IntegerMode Integers
UnsignedIntegerMode Unsigned integers
DoubleMode Values with decimal places
The number of decimal places is specified in "Dec‐
imalPlaces"
UnsignedDoubleMode Unsigned values with decimal places
The number of decimal places is specified in "Dec‐
imalPlaces"
Length Specified length
Angle Specified angle
LinearFeedPerTime Linear feed in mm/minute
LinearFeedPerRevolution Linear feed in mm/revolution
LinearFeedPerTooth Linear feed in mm/tooth
RevolutionSpeed Speed
ConstantCuttingSpeed Constant cutting rate
DecimalPlaces Number of decimal places if "DoubleMode" or "UnsignedDoubleMode" is selected
in the DisplayMode.
See example: Two decimal places are entered.
ItemType Field types in which a value is displayed.
TextField Input/output field for values and texts
TextFieldReadOnly Output field for values and texts
CheckBox Input/output field for states
CheckBoxReadOnly Output field for states
BitMask Bit mask for the display of a bit from a value. The bit mask is entered as integer
value. Bit 0 → 1, Bit 1 → 2, Bit 2 → 4
AccessLevel Value for the access level that is used for these parameters in the user interface.
Value range 1 to 7
UpperLimit Upper input limit for these parameters in the user interface.
Only applies for numerically entered parameters.
LowerLimit Lower input limit for these parameters in the user interface.
Only applies for numerically entered parameters.
Example
In the following example, the <GeoRadius> parameter is used.
Only enter the modified data.
<PARAMETERCONFIGURATION>
<GeoRadius>
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
250 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
