Siemens SINUMERIK 828D Commissioning Manual

<Width value="53" type="int" />
<DisplayMode value="DoubleMode" type="QString" />
<DecimalPlaces value="2" type="int" />
</GeoRadius>
</PARAMETERCONFIGURATION>
Configuring new list parameters based on an existing list parameter.
Assign a new parameter name and enter only the changed data:
Entries Meaning
Assign new parameter name
See example 1: Text "NewGeoRadius"
Base Name of the parameter on which the new parameter is based.
See example 1: "GeoRadius" parameter is used as a template.
Also enter only the changed data here. All other data is taken from the existing
parameter.
See example 1: Column width changed to 46 pixels. Number of decimal places
changed to 1.
Example 1
<PARAMETERCONFIGURATION>
<NewGeoRadius>
<Base value="GeoRadius" type="QString" />
<Width value="46" type="int" />
<DisplayMode value="DoubleMode" type="QString" />
<DecimalPlaces value="1" type="int" />
</NewGeoRadius>
</PARAMETERCONFIGURATION>
Example 2
Entries Meaning
Assign new cutting edge parameter name
The name is "EdgeUser_1_Bit0" in the following example.
Base Name of the parameter on which the new parameter is based.
In the following example, the "EdgeUser_1" parameter is used as template.
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 251

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
