Tag Meaning
translation Text, which is displayed at the user interface.
Label texts: You can only enter texts on one line. The "lines" entry is not applicable.
Tooltip: You can enter multi-line texts. A line break is set using the "%n" character.
chars Text length
The maximum text length is 30 characters.
lines Number of lines
The maximum number of lines is three.
remark Own comment - entry is not displayed at the user interface.
Procedure
1. You can copy the sample file "oem_slstepforms_deu.ts" from the following directory: /
siemens/sinumerik/hmi/template/lng
2. Save or create the file in the /oem/sinumerik/hmi/lng or /
user/sinumerik/hmi/lng directory.
3. Change the file name to "slstepforms_deu.ts".
If you require texts for additional languages, then a separate file must be created for each
language. Save the file with the appropriate language code in the file name.
4. Open the file and define the texts in the <message> and </message> areas.
5. Restart the system.
The file must still be converted into a binary format in order that the texts are displayed
during the program runtime. This data is only converted during power up.
Example of a file "slstepforms_deu.ts"
<?xml version="1.0" encoding="utf-8"?>
<!DOCTYPE TS><TS>
<context>
<name>SlStepLabels</name>
<message>
<source>T_LAB_USER_MACHINE_FUNC_1</source>
<translation>tool-specific function 1</translation>
<chars>20</chars>
</message>
<context>
<name>SlStepToolTip</name>
<!-- tooltips of user machine function 1-->
<message>
<source>T_TT_USER_MACHINE_FUNC_1</source>
<translation>User%nMachine functions 1</translation>
<chars>25</chars>
<lines>3</lines>
</message>
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
280 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
