F_T_REV2
TRANSM(_NR)
F_T_REV2
RET
Note
In the status display, TRANSM is now displayed instead of TRANSMIT.
Additional parameter assignments
For the used mirrorings
of the X and Y axes and the offsets of the C axis, the following machine
data has to be configured:
MD24006 $MC_CHSFRAME_RESET_MASK Active system frames after RESET
Bit 4 = 1 System frame for workpiece reference remains active after RESET
MD24007 $MC_CHSFRAME_RESET_CLEAR_MASK Clear system frames after RESET
Bit 4 = 0 Do not clear system frame workpiece reference after RESET
MD28082 $MC_MM_SYSTEM_FRAME_MASK Setting-up system frames (SRAM)
Bit 4 = 1 Workpiece reference ($P_WPFRAME)
MD28083 $MC_MM_SYSTEM_DATAFRAME_MASK Setting-up data management, system
frames (SRAM)
Bit 4 = 1 Workpiece reference ($P_WPFRAME)
Due to the coordinate system being mirrored, the following machine/setting data must be set:
MD21202 $MC_LIFTFAST_WITH_MIRROR Lift fast with mirror
= 1 For the determination of the lifting direction, it is also mirrored for active mirroring. The
mirroring of the lifting direction only refers to the direction components perpendicular to
the tool direction.
SD42910 $SC_MIRROR_TOOL_LENGTH Sign change, tool wear when mirroring
= 1 Inverting the sign mirrors the wear values of the tool length components whose associated
axes are mirrored.
General conditions
● The taper turning is not enabled for "working with two toolholders".
● The B-axis function (kinematics) is also not enabled for "working with two toolholders".
