Siemens SINUMERIK 828D Commissioning Manual

Display data Meaning
Servo gain factor (calculated) The servo gain factor in the display is calculated by the NC according
to the following equation:
.YIDFWRU 
6SHHGVHWSRLQW
)ROORZLQJHUURU
8QLWIRUGHIDXOWVHWWLQJ
>
PPLQ@
>PP@


Velocity setpoint = setpoint currently being output to the axis/spindle
References:
Basic Functions Function Manual; Velocities, Setpoint / Actual Value
Systems, Closed-Loop Control (G2)
Active measuring system 0: No measuring system active.
1: Measuring system 1 active.
2: Measuring system 2 active.
State of measuring system 1
State of measuring system 2
The state of measuring system 1 or 2 is output here:
Active - Parked - Passive
Actual position value measur‐
ing system 1
The actual position of the axis measured via measuring system 1 or 2.
The position is displayed in the machine coordinate system (no work
offsets or tool offsets taken into account).
Unit: mm, inch or degrees
Actual position value measur‐
ing system 2
Position setpoint Specified position transferred from the interpolator to the position control
Unit: mm, inch or degrees
Absolute compensation value
measuring system 1
Display of the absolute compensation value for measuring system 1 or
2.
The
compensation value consists
of the sum of backlash and leadscrew
error compensation for the actual axis position.
Unit: mm, inch or degrees
Absolute compensation value
measuring system 2
Compensation, sag + tem‐
perature
Display of the compensation value calculated for the current axis posi‐
tion based on the total of the sag and temperature compensations.
Unit: mm, inch or degrees
Actual speed value, active
encoder
The pulses supplied by the encoder are evaluated by the NC and dis‐
played.
Unit: %
100% means maximum speed.
Speed setpoint, drive Speed setpoint transferred to the drive (= speed setpoint from position
controller and feedforward control).
Unit: %
100% means maximum speed setpoint.
Programmed spindle speed
setpoint
Speed setpoint programmed by the user.
Unit: rpm
For example: Input: S1000; display: 1000 rpm
Display applies to spindles only.
Service and diagnostics
10.2 Displaying the Service overview
SINUMERIK Operate
330 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
