Press the "Drive selection" softkey.
The "Drive Direct Selection:" window opens.
Select the desired drive directly from the selection list.
6. Confirm the selection with "OK."
The drive data is displayed.
Overview
The individual status displays, warnings, messages, etc. that are displayed in the "Service
Drive" window are explained in the following.
PLC pulse enable
The display, whether the pulse enable from the PLC is available for the drive corresponds to
the interface signal:
DB380x, ... DBX4001.7 "Pulse enable".
Status Meaning Display
1 Pulse enable for this drive is activated by the PLC. Yes
0 The pulses for the drive module are disabled from the PLC. No
Speed controller enable NC
The display, whether the speed controller enable from the NC is available for the drive
corresponds to the interface signal:
DB390x ... DBX1.6 "Speed controller active".
Status Meaning Display
1 Speed controller enable from the NC present. Yes
0 Speed controller enable from the NC not present. No
Rampup function generator quick stop
The status display for the ramp-function generator quick stop corresponds to the interface
signal:
DB3900 ... DBX4000.1 "Ramp-function generator disable active".
Status Meaning Display
1 Ramp-up function generator quick stop is active. The drive is stopped without
a ramp function with speed setpoint = 0 and without pulse suppression.
Yes
0 Ramp-up function generator quick stop is not active for the drive. No
Service and diagnostics
10.2 Displaying the Service overview
SINUMERIK Operate
334 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
