Pulses enabled
The message whether the
pulses have been enabled for the drive corresponds to the interface
signal:
DB390x, ... DBX4001.7 "Pulses enabled".
Status Meaning Display
1 The drive module pulses are enabled. The axis/spindle can now be traversed. Yes
0 The drive module pulses are suppressed. The axis/spindle can therefore not
be traversed.
No
Drive ready
The display of the current status of the selected drive corresponds to the interface signal:
DB390x, ... DBX4001.5 "Drive ready".
Status Meaning Display
1 The drive is ready. Yes
0 The drive is not ready. No
Ramp-up phase
The display of the current ramp-up phase of the selected drive corresponds to the drive
parameter:
r0002 "Drive operating display".
Number of faulty signs-of-life
Display of communications errors detected in hardware between NC and drive.
Note
If the display shows a value other than "0", please contact your Siemens regional office!
SC1 drive alarm message
Displays (yes/no) whether messages of status class 1 are active. Status class 1 messages
are alarms with the following properties:
● They lead to internal responses (e.g. regenerative braking, immediate pulse suppression)
● They are modal.
This is
a group message. For details on the actually pending drive alarms, please refer to the
"Drive System Diagnostics" window, see Service drive (Page 333).
Service and diagnostics
10.2 Displaying the Service overview
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 335
