Parking axis
Displays (yes/no) whether it is a parking axis/spindle.
Note
With parking axes/spindles, all encoder-specific monitoring and evaluation functions are
switched off. This allows the encoder to be withdrawn without initiating an alarm.
Specified drive data set
The display (standard: DDS0) of which of the eight drive parameter sets is to be activated by
the PLC corresponds to the interface signal:
DB380x, ... DBX4001.0 to 4001.2 "Drive parameter set selection A, B, C".
Actual drive data set
The display (standard: DDS0) of which of the eight drive parameter sets is currently active
corresponds to the interface signal:
DB390x, ... DBX4001.0 to 4001.2 "Active drive parameter set A, B, C".
Specified motor data set
The display (MDS0...3) of which motor data set is to be activated by the PLC corresponds to
the interface signal:
DB380x, ... DBX4001.3 to 4001.4 "Motor selection A, B".
The following assignment applies:
Motor data set Coding
MDS0 0 0
MDS1 0 1
MDS2 1 0
MDS3 1 1
Actual motor data set
The
display
(MDS0...3)
of
which motor data set is currently active corresponds to the interface
signal:
DB390x, ... DBX4001.3 to 4001.4 "Active motor A, B".
Operating mode
The display of the control type of a drive corresponds to the drive parameter:
p1300[0…n] "Open-loop/closed-loop control mode".
Service and diagnostics
10.2 Displaying the Service overview
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 337
