Depending on "n", the following "values" are displayed:
n Display
20 Speed control (without encoder)
21 Speed control (with encoder)
23 Torque control (with encoder)
Position actual value measuring system 1/2
The actual position of
the axis as measured via measuring system 1/2. The position is displayed
in the machine coordinate system (no zero offsets or tool offsets included).
Unit: mm, inches or degrees
Heat sink temperature
The display of whether the heat sink temperature is OK corresponds to the interface signal:
DB3390x, ... DBX4002.1 "Heat sink temperature prewarning".
Status Meaning Display
1 The drive signals a "Heat sink temperature prewarning" to the PLC. Overtemper‐
ature
0 The drive module heat sink temperature pre-warning has not responded. OK
Motor temperature
The display of whether the motor temperature is OK corresponds to the interface signal:
DB390x, ... DBX4002.0 "Motor temperature prewarning".
Status Meaning Display
1 The motor temperature has exceeded the warning threshold configured in
the drive.
Overtemper‐
ature
0 The motor temperature is below the warning threshold. OK
Ramp-up function completed
The status display of the drive as to whether the ramp-up has been completed corresponds
to the interface signal:
DB390x, ... DBX4002.2 "Ramp-up completed".
Status Meaning Display
1 The actual speed value has reached the speed tolerance band specified via
p2164 after a new
speed setpoint specification and has not left the band for
the duration of p2166.
Yes
0 The ramp-up procedure is still active after the speed setpoint has been
changed.
No
Service and diagnostics
10.2 Displaying the Service overview
SINUMERIK Operate
338 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
