Siemens SINUMERIK 828D Commissioning Manual

Tag identifier Meaning
SOFTKEY_BACK The tag defines the response of the softkey "Back".

%DFN
The following additional actions can be defined within the softkey block:
● navigation
● update_controls
● function
Syntax:
<SOFTKEY_BACK>
…
…
</SOFTKEY_BACK>
SOFTKEY_ACCEPT The tag defines the response of the softkey "Accept".
$FFHSW
The following additional actions can be defined within the softkey block:
● navigation
● update_controls
● function
Syntax:
<SOFTKEY_ACCEPT>
…
…
</SOFTKEY_ACCEPT>
TEXT The tag is used to display a text in the specified position.
If an alarm number is used, the dialog box displays the text which is saved for the number.
Syntax:
<TEXT xpos = "<X position>" ypos = "<Y position>"> Text </TEXT>
Attributes:
● xpos
X position of the top left corner
● ypos
Y position of the top left corner
● color
Text color (see Chapter "Color coding
(Page 42)")
Value:
Text to be displayed
Generating user dialogs
1.6 XML identifier
Easy XML
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 65

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
