Tools
●
UTF8-capable editor (e.g. the integrated editor of the user interface or Notepad)
● A graphics program is needed to create graphics/display images.
File names and coding
Note
When
using HMI Operate in the NCU, note that all file names are written in lower case letters
(com, png, txt) on the CF card. This is required because of Linux.
On the PCU, you can write file names either in upper case or lower case letters. However, it
is recommended that you also use lower case letters here, in case of a possible subsequent
transfer to Linux.
Note
Make sure that the coding is set to UTF-8 in the editor that you are using when saving the
configuration and language files.
Storage paths
Note the following convention when storing the configuration files, language files, etc.
[System Siemens directory]
Linux: /card/siemens/sinumerik/hmi
Windows 7: C:\ProgramData\Siemens\MotionControl\siemens
[System oem directory]
Linux: /card/oem/sinumerik/hmi
Windows 7: C:\ProgramData\Siemens\MotionControl\oem
[System user directory]
Linux: /card/user/sinumerik/hmi
Windows 7: C:\ProgramData\Siemens\MotionControl\user
[System add_on directory]
Linux: /card/addon/sinumerik/hmi
Windows 7: C:\ProgramData\Siemens\MotionControl\addon
Storage locations
"Run MyScreens" configuration:
[System oem directory] /proj
Configuration file:
[System oem directory] /cfg
Language files:
[System oem directory] /lng
Introduction
SINUMERIK Integrate Run MyScreens
10 Programming Manual, 10/2015, 6FC5397-3DP40-5BA3
