Siemens SINUMERIK 828D

Image files:
[System oem directory] /Ico/ico [Resolution]
Example:
[System oem directory] /Ico/ico640
Online Help:
[System oem directory] /hlp/ [Language]
Example:
[System oem directory] /hlp/eng
Application
You can implement the following functions:
Display dialogs containing the fol‐
lowing elements:
● Softkeys
●
Variables
● Texts and Help texts
● Graphics and Help displays
Open dialogs by:
● Pressing the (start) softkeys
●
Selection from the PLC/NC
Restructure dialogs dynamically:
● Edit and delete softkeys
●
Define and design variable fields
● Insert, exchange and delete display texts (language-
dependent or independent)
● Insert, exchange and delete graphics
Initiate operations in response to
the following actions:
● Displaying dialogs
●
Input values (variables)
● Select a softkey
● Exiting dialogs
● Value change of a system or user variable
Data exchange between dialogs:
Variables:
● Read (NC, PLC and user variables)
●
Write (NC, PLC and user variables)
● Combine with mathematical, comparison or logic operators
Execute functions:
● Subprograms
●
File functions
● PI services
Apply protection levels according to
user classes
Introduction
SINUMERIK Integrate Run MyScreens
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 11
