; Softkey definition in the dialog
HS1=("")
HS2=("")
HS3=("")
HS4=("")
HS5=("")
HS6=("")
HS7=("")
HS8=("")
VS1=("")
VS2=("")
VS3=("")
VS4=("")
VS5=("")
VS6=("")
VS7=("Next Mask")
VS8=("EXIT")
; Definition LOAD block
LOAD
; Read value with RNP
ACHS_NAM1 = RNP("$MC_AXCONF_GEOAX_NAME_TAB[0]")
ACHS_NAM2 = RNP("$MC_AXCONF_GEOAX_NAME_TAB[1]")
ACHS_NAM3 = RNP("$MC_AXCONF_GEOAX_NAME_TAB[2]")
; Output of a dialog line
DLGL("Value R2: = " << RNP("$R[2]"))
; Write WNP to a value
WNP("$R[3]",VAR0)
; Vertical dividing line
V_SEPARATOR(360,1,6,1)
; Horizontal dividing line
H_SEPARATOR(220,1,7,1)
END_LOAD
; Press method
PRESS(VS7)
; Load an additional dialog
LM("MASK2")
; End identifier press method
END_PRESS
; Press method
PRESS(VS8)
Getting Started
2.2 Example
SINUMERIK Integrate Run MyScreens
18 Programming Manual, 10/2015, 6FC5397-3DP40-5BA3

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
