MD number Designation Default set‐
ting
Recom‐
mendation
Data
class
Parameter
32432[0] $MA_PATH_TRANS_JERK_LIM 1000000 1000000 I DYNNORM
32432[1] $MA_PATH_TRANS_JERK_LIM 1000000 1000000 I DYNPOS
32432[2] $MA_PATH_TRANS_JERK_LIM 1000000 1000000 I DYNROUGH
32432[3] $MA_PATH_TRANS_JERK_LIM 20 20 I DYNSEMIFIN
32432[4] $MA_PATH_TRANS_JERK_LIM 20 20 I DYNFINISH
32620 $MA_FFW_MODE 3 3 M DYNNORM
32640 $MA_STIFFNESS_CONTROL_ENABLE 1 1 M DSC
33120 $MA_PATH_TRANS_POS_TOL 0,005 0,005 U --
Setting data:
MD number Designation Default set‐
ting
Recom‐
mendation
Data
class
Parameter
42470 $SC_CRIT_SPLINE_ANGLE 36° 36° U --
42471 $SC_MIN_CURV_RADIUS 1 1 M --
42500 $SC_SD_MAX_PATH_ACCEL 10000 10000 U --
42502 $SC_IS_SD_MAX_PATH_ACCEL 0 0 U --
42510 $SC_SD_MAX_PATH_JERK 10000 10000 U --
42512 $SC_IS_SD_MAX_PATH_JERK 0 0 U --
Parameterizing machine data
4.4 Machine data for Advanced Surface
CNC commissioning
84 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
