102 007-4486-001
Chapter 3: Installing or Removing Peripherals
• Mono microphone in (3.5 mm phono)
The rear panel audio ports support:
• Stereo line out (3.5-mm phono)
• Embedded microphone in the O2Cam
Connecting Video Devices
Note: The video option is not available on all models.
Your workstation can send and receive analog composite video (RCA) and S-video
(MiniDIN) signals. In addition, the digital camera port provides a digital video input and
output signal. The signal is proprietary to SGI and is similar to the parallel D-1 signal
used in professional video applications.
The analog S-video and analog composite video ports accept most consumer and
industrial-grade video equipment.
For cable pinout information, see Hardware Central. (If your Web browser is not loaded,
it takes a few seconds to load.) Or, if you are viewing this on a remote server, see “Cable
Pinout Assignments” in Appendix A.
Note: Connect the O2Cam before turning on the workstation, so that the system
recognizes the camera.
