Chapter 1: Getting Started
Figure 1-3 shows the rear view of the R12000class workstation.
Figure 1-3 Rear View of the O2+ R12000class Workstation
* Not all models
Power connector
SCSI
Parallel
Monitor
Ethernet
10/100-Base T
Serial 2
Serial 1
Keyboard
2
1
System
module
Display
adapter
option
System disk
Stereo audio out
Camera/digital
video I/O*
Mouse
PCI option
