Silicon Graphics O2+ - Figure 5-37 Removing the Bezel from the Power Supply

Replacing the Power Supply
007-4486-001 151
3. To release the bezel that covers the power supply, press the latch at the top of the
bezel (Figure 5-37). It swings out toward you. Remove it from the chassis.
Figure 5-37 Removing the Bezel from the Power Supply
