Silicon Graphics O2+ - Presenter 1280 Flat Panel Adapter (Optional); Table A-10 Presenter 1280 Monitor Port (Optional)

200 007-4486-001
A: Technical Specifications
Presenter 1280 Flat Panel Adapter (Optional)
Table A-10 shows the cable pinout assignments for the optional Presenter 1280 adapter
board.
Table A-10 Presenter 1280 Monitor Port (Optional)
Pin Assignment Pin Assignment
1 RED_P[0] 35 RED_P[1]
2 RED_N[0] 36 RED_N[1]
3 RED_P[2] 37 RED_P[3]
4 RED_N[2] 38 RED_N[3]
5 RED_P[4] 39 RED_P[5]
6 RED_N[4] 40 RED_N[5]
7 RED_P[6] 41 RED_P[7]
8 RED_N[6] 42 RED_N[7]
9 GRN_P[0] 43 GRN_P[1]
10 GRN_N[0] 44 GRN_N[1]
11 GRN_P[2] 45 GRN_P[3]
12 GRN_N[2] 46 GRN_N[3]
13 GRN_P[4] 47 GRN_P[5]
14 GRN_N[4] 48 GRN_N[5]
15 GRN_P[6] 49 GRN_P[7]
16 GRN_N[6] 50 GRN_N[7]
17 BLUE_P[0] 51 BLUE_P[1]
18 BLUE_N[0] 52 BLUE_N[1]
19 BLUE_P[2] 53 BLUE_P[3]
20 BLUE_N[2] 54 BLUE_N[3]
21 BLUE_P[4] 55 BLUE_P[5]
