Silicon Graphics O2+ - Stereo View; Table A-9 Optional Stereo View Port Pin Assignments

Cable Pinout Assignments
007-4486-001 199
Stereo View
Table A-9 shows the cable pinout assignments for the stereo view port on the optional
Presenter 1280/stereo view adapter board.
5 GROUND
6 RED RETURN
7 GREEN RETURN
8 BLUE RETURN
9 +5V, limited current
10 GROUND
11 RESERVED
12 IIC DATA
13 HORIZONTAL SYNC
14 VERTICAL SYNC
15 IIC CLOCK
Table A-9 Optional Stereo View Port Pin Assignments
Pin Assignment
1 STEREO POWER (+12V, 0.5A)
2 STEREO GROUND
3 VERTICAL - ODD FIELD
Table A-8 (continued) Monitor Port (DSUB15) Pinout Assignments
Pin Assignment
