Chapter 2
2. Installing or Removing Memory and Option Boards
This chapter explains how to install or remove DIMMs (double in-line memory
modules), PCI option boards, or a digital display option board. The following topics are
covered:
• “Removing the System Module”
• “Installing Memory Modules”
• “Removing Memory Modules”
• “Installing a PCI Board in an RM7000class Workstation”
• “Removing a PCI Board in an RM7000class Workstation”
• “Installing a PCI Board in an R12000class Workstation”
• “Removing a PCI Board in an R12000class Workstation”
• “Installing an Option Board”
• “Removing an Option Board”
• “Reinstalling the System Module”
• “Verifying the Hardware Installation”
Caution: Boards and DIMMs are extremely sensitive to static electricity. Handle the
boards carefully, and wear the wrist strap while installing the hardware.
Removing the System Module
Before installing memory or option boards, you must follow these steps:
!
