Silicon Graphics O2+ - Audio

194 007-4486-001
A: Technical Specifications
Audio
Figure A-1 shows the cable pinout assignments for the audio ports.
29 GROUND 63 -REQ
30 GROUND 64 -I/O
31 GROUND 65 -DB(8)
32 GROUND 66 -DB(9)
33 GROUND 67 -DB(10)
34 GROUND 68 -DB(11)
Table A-5 (continued) SCSI Port Pinout Assignments
Pin Assignment Pin Assignment
