Silicon Graphics O2+ - Figure 5-21 Removing the Power Cables

138 007-4486-001
Chapter 5: Ordering, Removing, Upgrading, Installing Replacement Parts
2. Remove the power cable from the rear (Figure 5-21).
Note: The illustrations show an RM7000class workstation. The process of replacing
the system drive is the same on an R12000class workstation.
Figure 5-21 Removing the Power Cables
