Silicon Graphics O2+ - Figure 2-42 Replacing the PCI Tray in the System Module

62 007-4486-001
Chapter 2: Installing or Removing Memory and Option Boards
Figure 2-42 Replacing the PCI Tray in the System Module
3. Push the tray down firmly until it is completely seated. You hear a click as it seats
(Figure 2-43).
Caution: If the PCI tray is not completely seated, the system module will not slide
back into the chassis.
!
