Silicon Graphics O2+ - Ethernet 10-Base T;100-Base T; Table A-3 Ethernet 10-Base T;100-Base T Port Pinout Assignments

Cable Pinout Assignments
007-4486-001 191
Ethernet 10-Base T/100-Base T
Table A-3 shows the cable pinout assignments for the Ethernet 10-Base T/100-Base T
port.
6 DATA 1 24 SIGNAL GROUND (DATA 1)
7 DATA 2 25 SIGNAL GROUND (DATA 2)
8 DATA 3 26 SIGNAL GROUND (DATA 3)
9 DATA 4 27 SIGNAL GROUND (DATA 4)
10 DATA 5 28 SIGNAL GROUND (DATA 5)
11 DATA 6 29 SIGNAL GROUND (DATA 6)
12 DATA 7 30 SIGNAL GROUND (DATA 7)
13 DATA 8 31 SIGNAL GROUND (DATA 8)
14 nINIT 32 SIGNAL GROUND (nINIT)
15 nSTROBE 33 SIGNAL GROUND (nSTROBE)
16 nSELECTIN 34 SIGNAL GROUND (nSELECTIN)
17 nAUTOFD 35 SIGNAL GROUND (nAUTOFD)
18 HOST LOGIC HIGH 36 PERIPHERAL LOGIC HIGH
Table A-3 Ethernet 10-Base T/100-Base T Port Pinout Assignments
Pin Assignment
1 TRANSMIT+
2 TRANSMIT–
3 RECEIVE+
4 (Reserved)
5 (Reserved)
Table A-2 (continued) Parallel Port (IEEE 1284-C) Pinout Assignments
Pin Assignment Pin Assignment
