Silicon Graphics O2+ - Digital Video Option Port (Optional); Table A-11 DB-9 Connector Pinout Assignments

Cable Pinout Assignments
007-4486-001 201
Digital Video Option Port (Optional)
Table A-11 shows the pinout assignments for the DB-9 connector on the O2+ digital video
option board.
22 BLUE_N[4] 56 BLUE_N[5]
23 BLUE_P[6] 57 BLUE_P[7]
24 BLUE_N[6] 58 BLUE_N[7]
25 FP_PIXEL_CLK_P 59 FP_HSYNC_CLK_P
26 FP_PIXEL_CLK_N 60 FP_HSYNC_CLK_N
27 FP_VSYNC_CLK_P 61 FP_AUDIO_R-P
28 FP_VSYNC_CLK_N 62 FP_AUDIO_R-N
29 POWERGOOD 63 FP_AUDIO_L-P
30 RESERVED 64 FP_AUDIO_L-N
31 CABLE_GND 65 CABLE_GND
32 CABLE_GND 66 CABLE_GND
33 FP_I
2
C_DATA 67 FP_I
2
C_CLK
34 CABLE_GND 68 CABLE_GND
Table A-11 DB-9 Connector Pinout Assignments
Pin Assignment
1 Analog Video Genlock In
2 Analog Video Genlock Gnd
3 GPI In
4 GPI In Gnd
5NC
Table A-10 (continued) Presenter 1280 Monitor Port (Optional)
Pin Assignment Pin Assignment
