Replacing the RM7000class CPU Module
007-4486-001 123
6. Grasp the CPU module on both sides and gently rock it out (Figure 5-5). Do not
exaggerate the rocking motion because you should not bend the pins.
Figure 5-5 Removing the RM7000class CPU Module
