Chapter 2: Installing or Removing Memory and Option Boards
Now that you have removed the system module, you can perform the following
activities:
• To install memory, see “Installing Memory Modules.”
• To remove memory, see “Removing Memory Modules.”
• To install a PCI option board in an RM7000class workstation, see “Installing a PCI
Board in an RM7000class Workstation.”
• To remove a PCI option board in an RM7000class workstation, see “Removing a PCI
Board in an RM7000class Workstation.”
• To install a PCI option board in an R12000class workstation, see “Installing a PCI
Board in an R12000class Workstation.”
• To remove a PCI option board in an R12000class workstation, see “Removing the
PCI Tray in an R12000class Workstation.”
• To install a digital display option board, see “Installing an Option Board.”
• To remove a digital display option board, see “Removing an Option Board.”
Installing Memory Modules
To see a 3D animation of installing memory modules, see Hardware Central. When the
browser window opens, see “Hardware Overview” and then “Installing Memory
Modules.” (If your Web browser is not loaded, it takes a few seconds to load.) If you are
viewing this on a remote server, the 3D animation is not available.
Caution: The O2+ workstation uses DIMMs (Double Inline Memory Modules). DIMMs
are extremely sensitive to static electricity. Handle the modules carefully, and wear the
wrist strap while installing them.
Note: The illustrations show an O2+ RM7000class workstation. The process of installing
and removing memory modules is the same for the O2+ R12000class workstation. Also
note that DIMMs cannot be installed on earlier workstations that used SIMMs.
!
