Silicon Graphics O2+ - Keyboard and Mouse; Scsi; Table A-4 Keyboard and Mouse Ports (6-Pin Minidin) Pinout Assignments; Table A-5 SCSI Port Pinout Assignments

192 007-4486-001
A: Technical Specifications
Keyboard and Mouse
Table A-4 shows the cable pinout assignments for the keyboard and mouse ports.
SCSI
Table A-5 shows the cable pinout assignments for the SCSI port.
6 RECEIVE–
7 (Reserved)
8 (Reserved)
Table A-4 Keyboard and Mouse Ports (6-pin MiniDIN) Pinout Assignments
Pin Assignment
1 KEYBOARD/MOUSE DATA
2 (Reserved)
3 GROUND
4 KEYBOARD/MOUSE POWER (+5V)
5 KEYBOARD/MOUSE CLOCK
6 (Reserved)
Table A-5 SCSI Port Pinout Assignments
Pin Assignment Pin Assignment
1 GROUND 35 -DB(12)
2 GROUND 36 -DB(13)
3 GROUND 37 -DB(14)
4 GROUND 38 -DB(15)
Table A-3 (continued) Ethernet 10-Base T/100-Base T Port Pinout Assignments
Pin Assignment
