Cable Pinout Assignments
007-4486-001 193
5 GROUND 39 -DB(P1)
6 GROUND 40 -DB(0)
7 GROUND 41 -DB(1)
8 GROUND 42 -DB(2)
9 GROUND 43 -DB(3)
10 GROUND 44 -DB(4)
11 GROUND 45 -DB(5)
12 GROUND 46 -DB(6)
13 GROUND 47 -DB(7)
14 GROUND 48 -DB(P)
15 GROUND 49 GROUND
16 GROUND 50 GROUND
17 TERMPWR 51 TERMPWR
18 TERMPWR 52 TERMPWR
19 OPEN 53 OPEN
20 GROUND 54 GROUND
21 GROUND 55 -ATN
22 GROUND 56 GROUND
23 GROUND 57 -BSY
24 GROUND 58 -ACK
25 GROUND 59 -RST
26 GROUND 60 -MSG
27 GROUND 61 -SEL
28 GROUND 62 -C/D
Table A-5 (continued) SCSI Port Pinout Assignments
Pin Assignment Pin Assignment
