208 007-4486-001
A: Technical Specifications
Physical Environment Specifications
Table A-19 lists the physical environment specifications for the O2+ workstation.
Table A-19 Physical Environment Specifications for the O2+ Workstation
Workstation dimensions 12 in. H x 9 in. D x 5 in. W
Power requirements 100 - 132 VAC, 2.4 - 1.8 A
200 - 264 VAC, 1.2 - 0.9 A
47 - 63 Hz
3-pin, earth-grounded plug
Ambient temperature +10° C to 35° C (operating)
-40° C to +65° C (non-operating)
Relative humidity 10% to 80% operating (no condensation)
5% to 90% non-operating (no condensation)
Heat dissipation 245 watts
Altitude 10,000 feet (operating)
40,000 feet (non-operating)
Vibration (operating) 0.02 inches displacement, 5-19 Hz
0.25 g, 5 - 100 Hz
Dwelling at each resonant frequency for 15 minutes
Vibration (non-operating) 0.1 inches displacement, 5-19 Hz
0.5 g, 5 - 500 Hz
Noise 35 dB (A) in typical operating position
Shock (operating) 5 g for 15 msec, half sine pulse in horizontal plan
7.5 g for 10 msec, half sine pulse in vertical plan
Shock (non-operating) 20 g for 10 msec, half sine pulse in all plans
