202 007-4486-001
A: Technical Specifications
Serial Cables and Converters
This section contains cable pinout information for serial cables that you can connect to
your O2+ workstation. It also describes Silicon Graphics serial port converters. The
following topics are covered:
• “Printer/Dumb Terminal Serial Cable”
• “PC Modem Serial Cable”
• “Serial Port Converters”
Printer/Dumb Terminal Serial Cable
For serial printers and dumb terminals, use a 3-wired standard PC cable. Table A-12
shows the cable connector pinout assignments for this cable.
6 Analog Video Genlock loopthrough
7 Analog Video Genlock Gnd
8 GPI Out
9 GPI Out Gnd
Table A-11 (continued) DB-9 Connector Pinout Assignments
Pin Assignment
