Silicon Graphics O2+ - Figure 6-4 Basic Parameters of VDT Workstation Adjustment

186 007-4486-001
Chapter 6: Safety and Regulatory Information
Figure 6-4 Basic Parameters of VDT Workstation Adjustment
Table 6-1 ANSI/HFS 100-1988 Guidelines for VDT Workplace Adjustment
Adjustment Small Female Midpoint Large Male
Seat pan height 40.6 cm (16.0 in) 46.3 cm (18.2 in) 52.0 cm (20.5 in)
Work surface height
(keyboard and mouse)
58.5 cm (23.0 in) 64.75 cm (25.5 in) 71.0 cm (28.0 in)
Screen viewing height 103.1 cm (40.6 in) 118.1 cm (46.5 in) 133.1 cm (52.4 in)
Screen viewing distance >30.5 cm (>12 in) >30.5 cm (>12 in) >30.5 cm (>12 in)
Screen viewing angle 0-60 degrees 0-60 degrees 0-60 degrees
0º-60º
Work
Surface
Height
Seat
Pan
Height
Screen
Viewing
Height
Screen
Viewing
Angle
Screen Viewing
Distance
