Silicon Graphics O2+ - Monitor; Table A-8 Monitor Port (DSUB15) Pinout Assignments

198 007-4486-001
A: Technical Specifications
Monitor
Table A-8 shows the cable pinout assignments for the O2+ monitor DSUB15 port.
21 INDATA2GND 55 OUTDATA2
22 INDATA2 56 OUTDATA2GND
23 INDATA1GND 57 OUTDATA1
24 INDATA1 58 OUTDATA1GND
25 INDATA0GND 59 OUTDATA0
26 INDATA0 60 OUTDATA0GND
27 INDATACLK 61 RESERVED
28 INDATACLKGND 62 RESERVED
29 RESERVED 63 RESERVED
30 -12V 64 +12V
31 RESERVED 65 RESERVED
32 RESERVED 66 RESERVED
33 RESERVED 67 RESERVED
34 RESERVED 68 RESERVED
Table A-8 Monitor Port (DSUB15) Pinout Assignments
Pin Assignment
1 RED
2 GREEN (complete sync in some modes)
3 BLUE
4 RESERVED
Table A-7 (continued) Digital Video Port for O2Cam
Pin Assignment Pin Assignment
