27.5.79 HRTIM ADC post scaler register 2 (HRTIM_ADCPS2)
Address offset: 0x404
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. ADC10PSC[4:0] Res. ADC9PSC[4:0] Res.
ADC8P
SC[4]
rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
ADC8PSC[3:0] Res. ADC7PSC[4:0] Res. ADC6PSC[4:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:29 Reserved, must be kept at reset value.
Bits 28:24 ADC10PSC[4:0]: ADC 10 post scaler
Refer to ADC1PSC[4:0] description.
Bit 23 Reserved, must be kept at reset value.
Bits 22:18 ADC9PSC[4:0]: ADC 9 post scaler
Refer to ADC1PSC[4:0] description.
Bit 17 Reserved, must be kept at reset value.
Bits 16:12 ADC8PSC[4:0]: ADC 8 post scaler
Refer to ADC1PSC[4:0] description.
Bit 11 Reserved, must be kept at reset value.
Bits 10:6 ADC7PSC[4:0]: ADC 7 post scaler
Refer to ADC1PSC[4:0] description.
Bit 5 Reserved, must be kept at reset value.
Bits 4:0 ADC6PSC[4:0]: ADC 6 post scaler
Refer to ADC1PSC[4:0] description.
